28 Getting Started

Figure 10. License Upgrade Screen

2. Once you have completed the upgrade, the window will reload with the E-MAIL and SNMP

tabs active. Click on the Close button in the confirmation window.

3. Click the Close button on the Settings window.

4. You can verify the change by clicking the About button and noting that it now displays (Global),

see ”About” beginning on page 102.

Also the notice displayed under the “Other Servers” section will now be removed and any remote

discovered StorView Servers will be displayed.
